Specification

1) COMPREHENSIVE FEATURE

Frequency range: UHF600-900MHz (Digital transmission)

The concrete frequency is decided by the technique provision of the system usage place

Digital modulation Mode: pi/4DQPSK

Occupied bandwidth:300KHz

Transmission rate: 204.8Ksps

S/N: 96dB

Frequency response: 30~20KHz

Receive mode: Digital decryption receive (fix frequency)

Sensitivity: -94dBm

2) TRANSMITTER SPECIFICATION

Transmit mode: Audio and data using encrypted word transmission

Dedicated data channel: 7kbps, internal CRC check

Capsule: dynamic

Transmitting power:≤10dBm

 Frequency stabilization:±0.005%

Battery: two piece batteries of 1.5V
